The UCPX12 pillow block bearing unit combines cast iron housing with a steel insert, providing strength, reliability, and long-lasting performance.
Key specifications
| (d) Bore diameter | 60mm |
| (J) Centre distance between bolt holes | 203mm |
| (N) Bolt hole diameter | 25mm |
| (T) Overall height | 153.5mm |
| (L) Overall Width | 72mm |
| (H) Overall length | 265mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
| (d) Bore diameter | 60mm |
| (J) Centre distance between bolt holes | 203mm |
| (N) Bolt hole diameter | 25mm |
| (T) Overall height | 153.5mm |
| (L) Overall Width | 72mm |
| (H) Overall length | 265mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
