The UCP215 pillow block bearing unit combines a cast iron housing with steel insert, delivering strength and dependable performance.
Key specifications
| (d) Bore diameter | 75mm |
| (J) Centre distance between bolt holes | 217mm |
| (N) Bolt hole diameter | 25mm |
| (T) Overall height | 164mm |
| (L) Overall Width | 73mm |
| (H) Overall length | 271.5mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
| (d) Bore diameter | 75mm |
| (J) Centre distance between bolt holes | 217mm |
| (N) Bolt hole diameter | 25mm |
| (T) Overall height | 164mm |
| (L) Overall Width | 73mm |
| (H) Overall length | 271.5mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
