The UCP205 pillow block bearing unit with cast iron housing and steel insert delivers dependable machinery support and long service life.
Key specifications
| (d) Bore diameter | 25mm |
| (J) Centre distance between bolt holes | 105mm |
| (N) Bolt hole diameter | 13mm |
| (T) Overall height | 70.5mm |
| (L) Overall Width | 38mm |
| (H) Overall length | 139.5mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
| (d) Bore diameter | 25mm |
| (J) Centre distance between bolt holes | 105mm |
| (N) Bolt hole diameter | 13mm |
| (T) Overall height | 70.5mm |
| (L) Overall Width | 38mm |
| (H) Overall length | 139.5mm |
| Housing type | Pillowblock |
| No of bolt holes | 2 |
| Material, housing | Cast iron |
| Material, bearing | Bearing steel |
